MT500VA-3000VA
- Small and delicate
- Wide input voltage range
- Excellent microprocessor ensures operation
- Automatic voltage regulation
- Automatic restart function for utility power
- Simulated sine wave
- Overview
- Related Products
-
Personal computer
-
Printer
-
POS(Point of sales) terminals
-
Security system
-
Fax machine
- Modem, router
APPLICATIONS:
Product parameters:
| Model | BT500 | |
| capacity | 500VA/300W | |
| Input | ||
| Input voltage | 1 10/120/200/220/230/240vac | |
| Input voltage range | 140 -280V | |
| Input frequency | 50±HZ | |
| output | ||
| BattEry voltage | 1 10/120/200/220/230/240vac | |
| output voltage range | ±10% | |
| output frequency | 50±HZ | |
| Transfer time | ≤6ms | |
| Battery | ||
|
Standard UPS |
Battery voltage | |
| Battery model | ||
| Battery quantity | ||
| charging time | 10- 1690% 10 - 16 Hours to 90% full capacity | |
| Model | BT500 | |
| External battery Ups | BattEry voltage | 12V |
| Battery model | External battEry | |
| Battery quantity | ||
| charging time | Depends on the external battery capacity | |
| Display description | ||
| Display status | LCD | |
| protection function | Automatic detection and discharge protection, input short circuit protection, overload protection | |
| Warning sound | ||
| Battery mode | 4 Beep every 4 seconds | |
| Low battery | Beep every second | |
| overload | Beep every second | |
| Error | continuous Beep | |
| Physical property | ||
|
stardard Ups |
size (MM) | |
| WEight(KG) | ||
|
External battery Ups |
size (MM) | 320*90* 140 |
| weight(KG) | 3.5 | |
|
Usage environment |
||
|
Humidity |
0-90%0-40℃ 0 -90% Humidity and 0-40 ℃ Temperature |
|
|
Noise |
<40db | |
Product parameters:
| Model | BT600 | |
| capacity | 600VA/360W | |
| Input | ||
| Input voltage | 1 10/120/200/220/230/240vac | |
| Input voltage range | 140 -280V | |
| Input frequency | 50±HZ | |
| output | ||
| BattEry voltage | 1 10/120/200/220/230/240vac | |
| output voltage range | ±10% | |
| output frequency | 50±HZ | |
| Transfer time | ≤6ms | |
| Battery | ||
|
Standard UPS |
Battery voltage | 12V |
| Battery model | 12V/7AH | |
| Battery quantity | ||
| charging time | 10- 1690% 10 - 16 Hours to 90% full capacity | |
| Model | BT600(S) | |
| External battery Ups | BattEry voltage | 12V |
| Battery model | External battEry | |
| Battery quantity | ||
| charging time | Depends on the external battery capacity | |
| Display description | ||
| Display status | LCD | |
| protection function | Automatic detection and discharge protection, input short circuit protection, overload protection | |
| Warning sound | ||
| Battery mode | 4 Beep every 4 seconds | |
| Low battery | Beep every second | |
| overload | Beep every second | |
| Error | continuous Beep | |
| Physical property | ||
|
stardard Ups |
size (MM) | 320*90* 140 |
| WEight(KG) | 5.1 | |
|
External battery Ups |
size (MM) | |
| weight(KG) | ||
|
Usage environment |
||
|
Humidity |
0-90%0-40℃ 0 -90% Humidity and 0-40 ℃ Temperature |
|
|
Noise |
<40db | |
Product parameters:
| Model | BT1000 | |
| capacity | 1KVA/600W | |
| Input | ||
| Input voltage | 1 10/120/200/220/230/240vac | |
| Input voltage range | 140 -280V | |
| Input frequency | 50±HZ | |
| output | ||
| BattEry voltage | 1 10/120/200/220/230/240vac | |
| output voltage range | ±10% | |
| output frequency | 50±HZ | |
| Transfer time | ≤6ms | |
| Battery | ||
|
Standard UPS |
Battery voltage | 24V |
| Battery model | 12V/9AH | |
| Battery quantity | ||
| charging time | 10- 1690% 10 - 16 Hours to 90% full capacity | |
| Model | BT1000(S) | |
| External battery Ups | BattEry voltage | 24V |
| Battery model | External battEry | |
| Battery quantity | ||
| charging time | Depends on the external battery capacity | |
| Display description | ||
| Display status | LCD | |
| protection function | Automatic detection and discharge protection, input short circuit protection, overload protection | |
| Warning sound | ||
| Battery mode | 4 Beep every 4 seconds | |
| Low battery | Beep every second | |
| overload | Beep every second | |
| Error | continuous Beep | |
| Physical property | ||
|
stardard Ups |
size (MM) | 365* 140* 165 |
| WEight(KG) | 5.7 | |
|
External battery Ups |
size (MM) | 365* 140* 165 |
| weight(KG) | 4.2 | |
|
Usage environment |
||
|
Humidity |
0-90%0-40℃ 0 -90% Humidity and 0-40 ℃ Temperature |
|
|
Noise |
<40db | |
Product parameters:
| Model | BT2000 | |
| capacity | 2KVA/1200W | |
| Input | ||
| Input voltage | 1 10/120/200/220/230/240vac | |
| Input voltage range | 140 -280V | |
| Input frequency | 50±HZ | |
| output | ||
| BattEry voltage | 1 10/120/200/220/230/240vac | |
| output voltage range | ±10% | |
| output frequency | 50±HZ | |
| Transfer time | ≤6ms | |
| Battery | ||
|
Standard UPS |
Battery voltage | 24V |
| Battery model | 12V/9AH | |
| Battery quantity | 2 | |
| charging time | 10- 1690% 10 - 16 Hours to 90% full capacity | |
| Model | BT2000(S) | |
| External battery Ups | BattEry voltage | 24V |
| Battery model | External battEry | |
| Battery quantity | ||
| charging time | Depends on the external battery capacity | |
| Display description | ||
| Display status | LCD | |
| protection function | Automatic detection and discharge protection, input short circuit protection, overload protection | |
| Warning sound | ||
| Battery mode | 4 Beep every 4 seconds | |
| Low battery | Beep every second | |
| overload | Beep every second | |
| Error | continuous Beep | |
| Physical property | ||
|
stardard Ups |
size (MM) | 365* 140* 1 65 |
| WEight(KG) | 12.6 | |
|
External battery Ups |
size (MM) | 395* 145*21 0 |
| weight(KG) | 10.2 | |
|
Usage environment |
||
|
Humidity |
0-90%0-40℃ 0 -90% Humidity and 0-40 ℃ Temperature |
|
|
Noise |
<40db | |
Product parameters:
| Model | BT3000 | |
| capacity | 3KVA/1800W | |
| Input | ||
| Input voltage | 1 10/120/200/220/230/240vac | |
| Input voltage range | 140 -280V | |
| Input frequency | 50±HZ | |
| output | ||
| BattEry voltage | 1 10/120/200/220/230/240vac | |
| output voltage range | ±10% | |
| output frequency | 50±HZ | |
| Transfer time | ≤6ms | |
| Battery | ||
|
Standard UPS |
Battery voltage | 24V |
| Battery model | 12V/9AH | |
| Battery quantity | 4 | |
| charging time | 10- 1690% 10 - 16 Hours to 90% full capacity | |
| Model | BT3000(S) | |
| External battery Ups | BattEry voltage | 24V |
| Battery model | External battEry | |
| Battery quantity | ||
| charging time | Depends on the external battery capacity | |
| Display description | ||
| Display status | LCD | |
| protection function | Automatic detection and discharge protection, input short circuit protection, overload protection | |
| Warning sound | ||
| Battery mode | 4 Beep every 4 seconds | |
| Low battery | Beep every second | |
| overload | Beep every second | |
| Error | continuous Beep | |
| Physical property | ||
|
stardard Ups |
size (MM) | 395* 145*210 |
| WEight(KG) | 21 | |
|
External battery Ups |
size (MM) | 395* 145*21 0 |
| weight(KG) | 13.7 | |
|
Usage environment |
||
|
Humidity |
0-90%0-40℃ 0 -90% Humidity and 0-40 ℃ Temperature |
|
|
Noise |
<40db | |
